Tantalum Tubing Shenzhen Sunrise Metal Industry Co.,Ltd

TANTALUM WELDED TUBEAll Alloys are stocked in Plate, Sheet, Strip, Bar and Wire. Shenzhen Sunrise Metal Industry Co.,Ltd also have large stocks of Molybdenum, TZM, Tungsten, Tungsten Heavy Alloy and Niobium.  Shenzhen Sunrise Metal Industry Co.,Ltd TEL：0086-0755-27185042  Website：http://www.sunriseta.com E-Mail：sales@sunriseta.com High on Shenzhen Sunrise Metal Industry Co.,Ltd’s list of fabricated products is its tantalum components for anti-corrosion equipment. The reason being, welded tantalum tube provides excellent corrosion resistance and heat transfer for chemical processing applications. Since no allowance for metal removal by corrosion is generally necessary, wall thicknesses are specified to be as thin as structural conditions will permit.

Tantalum welded tube

In particular, ULTRA 76 tantalum alloys offer higher corrosion resistance in most environments thus generating value by extending the products life time, reducing material thickness and improving processes throughput. For instance, higher temperatures are possible with shorter cooling/heating cycle times using ULTRA 76.

Shenzhen Sunrise Metal Industry Co.,Ltd’s welded tube is rolled and welded from annealed tantalum strip and has sufficient formability to meet requirements for most operations used in fabricating chemical process equipment.

Our tantalum welded tubes offer significantly better wall thickness and concentricity control compared to seamless tubes. Why? Because the wall thickness is constant across the tube, so this eliminates weak spots where leaks occur prematurely due to corrosion. Since no allowance for metal removal by corrosion is generally necessary, wall thicknesses are specified to be as thin as structural conditions will permit.

All Shenzhen Sunrise Metal Industry Co.,Ltd tantalum tubes exceed ASTM B 521.

Guaranteed Quality

• All standard tubing with 100% pressure, helium leak and ultrasonic test are tested for hermeticity
• All capped tubing is x-rayed at cap weld for hermeticity

High Quality Material Certifications

• TUV 3.1 certificated
• Shenzhen Sunrise Metal Industry Co.,Ltd is EICC certified, so our tantalum is purchased only from non-conflict sources

Better than Industry Standards

• Straight lengths to 30' and u-bends to 30' OAL are available
• Maximum tube length is the longest in the industry 12 m
• Constant surface finish (Ra<0.8 micrometers)
• Custom radius tube coils

Dimensions

Form	Thickness, Dia., Wall inches (mm) Width, Length inches (mm)
Welded Tubing	0.5“ OD x 0.015“ - 0.040“ wall (12.7 mm OD x 0.380 - 1.0 mm wall) 0.75“ OD x 0.015“ - 0.050“ wall (19.05 mm OD x 0.380 - 1.27 mm wall) 1.0 - 4.0“ OD x 0.015“ - 0.100“ wall (25.4 - 102 mm OD x 0.380 - 2.540 mm wall)

Please contact us for additional sizes and requirements.

Tantalum and Tantalum Alloy Products:

Refer to Product Data Sheets for Tantalum for sizes:

PD-7033 NRC Ultra 76 Tantalum Alloy (Ta 2.5%W)
PD-7035 NRC Tantalum (UNS R05200)
PD-7036 NRC Tantalum Beam Melted Tantalum (ETA) (UNS R05200)
